Description

Deye SUN-6K-OG01LP1-EU-AM2 is a high-performance 6kW hybrid inverter designed for residential and small commercial solar systems. It combines solar, battery, grid, and generator inputs in one smart device.

Engineered for residential and small commercial applications, this inverter seamlessly integrates solar, grid, battery, and generator inputs for maximum energy flexibility.

• • • Powerful Output: 6kW rated AC power, with peak off-grid power up to 12kW (2x rated, 10s).
    • High Charging Performance: Supports up to 140A charge/discharge current – ideal for fast battery cycling.
    • Flexible Battery Options: Compatible with both lithium-ion and lead-acid batteries.
    • Advanced MPPT: Dual MPPT trackers with >99% efficiency maximize solar harvest.
    • Smart Energy Scheduling: Set up to 6 customizable time periods for charging and discharging.
    • Grid & Generator Support: Store energy from both the grid and diesel generators – perfect for backup and off-grid systems.
    • Parallel Ready: Connect up to 16 units in parallel for larger systems – both on-grid and off-grid.
    • Retrofit Ready: AC coupling allows for easy integration into existing solar setups.
    • User-Friendly Interface: Colorful touch LCD and IP65-rated enclosure for outdoor use.

Remote Monitoring & Communication:

• • • Supports WiFi / GPRS / 4G / Bluetooth / LAN options
    • Interfaces: RS485, RS232, CAN

Safe and Certified:

• • • Equipped with DC switch, insulation impedance detection, residual current detection, and optional arc fault protection
    • Certified to meet international grid standards including VDE-AR-N 4105, EN 50549, G99, NRS 097, and more

Installation-Friendly Design:

• • Natural cooling system for silent operation
  • Compact size: 376 × 470 × 241.5 mm
