600W Shingled Solar Panel – High-Efficiency Mid-Cut Monofacial Double-Glass (N-Type, IP68)

In Stock

  • Cell Type: N-type monocrystalline, shingled

  • Number of Cells: 132 half-cells (6×22) or equivalent shingled layout

  • Cell Size: 210 mm × 210 mm

  • Module Dimensions: 2384 mm × 1303 mm × 33–35 mm

  • Weight: ~38–39 kg

  • Glass: Front – 2.0 mm AR-coated tempered; Back – 2.0 mm tempered

  • Frame: Anodized aluminum alloy

  • Bypass Diodes: 3

  • Cable: +600 mm / –1200 mm, 4 mm² cross-section, MC4 compatible

  • Junction Box Protection: IP6

  • Operating Temperature Range: –40 °C to +85 °C

  • Temperature Coefficient of Pmax: –0.26 %/°C

  • Temperature Coefficient of Voc: –0.24 %/°C

  • Temperature Coefficient of Isc: +0.04 %/°C

  • Maximum System Voltage: 1500 V DC

  • Maximum Series Fuse Rating: 30 A

  • Mechanical Load: Snow – 5400 Pa / Wind – 2400 Pa

  • Safety Class: Class II

Warranty & Certifications

  • Product Warranty: 15 years

  • Linear Power Output Warranty: 30 years (max 0.4 % annual degradation)

  • Certifications: CE, TUV, IEC 61215, IEC 61730, UL, CEC, PID-resistant

Original price was: ₦137,000.00.Current price is: ₦117,000.00.

Category: Tags: , Brand:

Description

Elevate your solar energy system with the Bluesun 600W Shingled Solar Panel, engineered for maximum performance, durability, and seamless integration.

Featuring cutting-edge shingled cell design with monofacial double-glass construction, this panel delivers exceptional efficiency and long-term reliability—ideal for both residential and commercial installations.

  • High Efficiency & Power Output
    Generates up to 600 W under Standard Test Conditions (STC), with panel efficiency rated at 23 %

  • Advanced Cell Technology
    Utilizes shingled cell architecture with N-type monocrystalline and PERC, offering outstanding conversion efficiency, bifacial energy capture, and rugged double-glass construction

  • Durable Construction
    Panel dimensions: 2384 × 1096 × 30 mm; weight: 40 kg. Includes IP68-rated junction box, anodized aluminum alloy frame, and robust double-glass build for enhanced longevity and resilience

  • Certified & Reliable
    Certified to meet CE, TUV, and IEC standards; protected with a 30-year linear power warranty—ensures long-term energy production with minimal degradation.
